| Allmänt |
| Typ av enhet | UPS - kan monteras i rack |
| Höjd (U-format) | 2U |
| Färg | Svart |
| Nätdel |
| UPS-teknik | Interaktiv |
| Inspänning | AC 120 V |
| Inspänningens område | AC 82 - 144 V |
| Inspänningens område (justeringsbart) | AC 75 - 154 V |
| Tillhandahållen frekvens | 57 - 63 Hz |
| Erforderlig frekvens | 50/60 Hz |
| Inmatningsanslutningar | 1 x ström, NEMA 5-15 |
| Kontaktdetaljer för uteffekt | 6 x ström, NEMA 5-15 |
| Utspänning | AC 120 V ± 5% - 57 - 63 Hz |
| Effektkapacitet | 1000 Watt / 1440 VA |
| Utvågform | Sinusvåg |
| Energivärdering | 459 joule |
| Batteri |
| Antal | 1 |
| Teknik | Bly-syra |
| Runtime (upp till) | 7 min vid full laddning
26 min vid halv maskin
335 min vid 50 Watt
190 min vid 100 Watt
92 min vid 200 Watt
56 min vid 300 Watt
37 min vid 400 Watt
26 min vid 500 Watt
19 min vid 600 watt
14 min vid 700 Watts
11 min vid 800 Watt
9 min vid 900 Watt
7 min vid 1 000 Watt |
| Laddningstid | 3 timmar |
| Nätverk |
| Gränssnitt för fjärradministration | USB |
| Expansion/Anslutning |
| Gränssnitt | 1 x hantering (USB) - 4-stifts USB typ B |
| Expansionskortplatser | 1 (totalt)/ 1 (ledig) x SmartSlot |
| Diverse |
| Medföljande kablar | Strömkabel - integrerad - 2.44 m |
| Egenskaper | Hörbart larm, LCD-bildskärm, LED-indikatorer |
| Standarder som följs | FCC klass A-certifierad, CSA, UL 1778, FCC Part 15, RoHS, REACH |
| Hållbarhetsinformation |
| ENERGY STAR | Ja |
| Tillverkarens garanti |
| Service och support | Begränsad garanti - 3 år
Begränsad garanti - batterier - 2 år |
| Miljöparametrar |
| Min temperatur vid drift | 0 °C |
| Max temperatur vid drift | 40 °C |
| Luftfuktighet vid drift | 0 - 95% |
| Ljudnivå | 46 dBA |
| Mått och vikt |
| Bredd | 43.2 cm |
| Djup | 45.7 cm |
| Höjd | 8.9 cm |
| Vikt | 28.64 kg |
| Mått och vikt (brutto) |
| Emballagets bredd | 59.4 cm |
| Emballagets djup | 60.3 cm |
| Emballagets höjd | 25.1 cm |
| Emballagets vikt | 31.91 kg |
| Kompatibilitetsinformation |
| Designat för | P/N: ACCS1000, ACCS1001, ACCS1002, ACCS1003, ACCS1004, ACCS1005, ACCS1006, ACCS1007, ACDC1015, ACDC1016, ACDC1017, ACDC1019, ACDC1020, ACDC1021, ACDC2513, ACF001, ACF002, ACF003, ACF101BLK, ACF102BLK, ACF201BLK, ACF400, ACF600, AP5017, AP5602, AP5606, AP5607, AP5616, AP92200, AP9290, AR100, AR100HD, AR202, AR203A, AR204A, AR2101, AR2102BLK, AR2144BLK, AR2145BLK, AR2200, AR2280, AR2400, AR2400FP1, AR2401, AR2407, AR2480, AR2487, AR2487G, AR2500, AR2507, AR2580, AR2587, AR2900, AR2901, AR3000, AR3100, AR3100G, AR3100SP, AR3100SP1, AR3100SP2, AR3100TAA, AR3100W, AR3100X609, AR3100X610, AR3100X617, AR3101, AR3104, AR3104SP1, AR3105, AR3105SP, AR3105W, AR3107, AR3107G, AR3107SP, AR3107X609, AR3107X610, AR3107X617, AR3130, AR3140, AR3140G, AR3140W, AR3150, AR3150SP, AR3150SP1, AR3150SP2, AR3150W, AR3150X609, AR3150X610, AR3150X617, AR3155, AR3155SP, AR3155W, AR3157, AR3157SP, AR3157X609, AR3157X610, AR3157X617, AR3200, AR3300, AR3300G, AR3300SP, AR3300W, AR3300X609, AR3300X610, AR3300X617, AR3305, AR3305SP, AR3305W, AR3307, AR3307SP, AR3307W, AR3307X609, AR3307X610, AR3307X617, AR3340, AR3340G, AR3340W, AR3347, AR3350, AR3350SP, AR3350W, AR3350X609, AR3350X610, AR3350X617, AR3355, AR3355SP, AR3355W, AR3357, AR3357SP, AR3357X609, AR3357X610, AR3357X617, AR4018, AR4018A, AR4018I, AR4018IA, AR4018IX429, AR4018IX431, AR4018IX432, AR4018SP, AR4018SPX429, AR4018SPX431, AR4018SPX432, AR4018X429, AR4018X431, AR4018X432, AR4024, AR4024A, AR4024I, AR4024IA, AR4024IX429, AR4024IX431, AR4024IX432, AR4024SP, AR4024SPX429, AR4024SPX431, AR4024SPX432, AR4024X429, AR4024X431, AR4024X432, AR4038, AR4038A, AR4038I, AR4038IA, AR4038IX429, AR4038IX431, AR4038IX432, AR4038X429, AR4038X431, AR4038X432, AR7007, AR7050, AR7057, AR8135BLK, NBWL0356A, SCL500RM1UC, SCL500RM1UNC, SMTL1000RM2UC, SMTL750RM2UC, SMX2000LVUS |
|
