| Allmänt |
| Typ av enhet | Nätverksadapter |
| Formfaktor | Instickskort - låg |
| Gränssnittstyp (buss) | PCI Express x1 |
| Nätverk |
| Anslutningsteknik | Kabelansluten |
| Typ av kablage | Ethernet 10Base-T, Ethernet 100Base-TX, Ethernet 1000Base-T |
| Datalänkprotokoll | 10Mb LAN, 100Mb LAN, GigE |
| Dataöverföringshastighet | 1 Gbps |
| Statusindikatorer | Länkaktivitet, portöverföringshastighet |
| Funktioner | Auto-negotiation, wake on LAN (WOL) |
| Standarder som följs | IEEE 802.3, IEEE 802.3u, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP) |
| Processor / Minne |
| Processor | 1 x 82574L - Intel |
| RAM | 32 KB |
| Expansion/Anslutning |
| Gränssnitt | 1 x nätverk - RJ-45 |
| Kompatibla kortplatser | 1 x PCI Express x1 |
| Diverse |
| Inkluderade tillbehör | Hållare för låg version |
| Standarder som följs | ACPI, FCC Klass B-certifierade, UL, VCCI Class B ITE, BSMI CNS 13438 Class A, CISPR 22 Class B, EN 60950, UL 1950, VCCI-II, EN55024, EN55022 Class B, ICES-003 Class B, MIC, ACA |
| Programvara / Systemkrav |
| Operativsystem erfordras | SuSE Linux Enterprise Server, SunSoft Solaris 9, SCO OpenServer 5.0.7, Microsoft Windows Server 2003 Enterprise Edition, Microsoft Windows Server 2003 Web Edition, Microsoft Windows Server 2003 Standard Edition, Microsoft Windows Server 2003, UnixWare 7.1.3, Novell NetWare 6.5, Microsoft Windows Small Business Server 2003, Red Hat Enterprise Linux, UnixWare 7.1.4, SunSoft Solaris 10, Microsoft Windows Server 2003 Standard x64 Edition, Microsoft Windows Server 2003 Enterprise x64 Edition, SCO OpenServer 6 |
| Dimensioner och vikt |
| Djup | 13 cm |
| Höjd | 5.6 cm |
| Miljöparametrar |
| Min temperatur vid drift | 0 °C |
| Max temperatur vid drift | 55 °C |
| Luftfuktighet vid drift | 10 - 95% |
| Kompatibilitetsinformation |
| Designat för | HPE ProLiant DL120 G7, DL120 G7 Base, DL120 G7 Entry, DL120 G7 Performance, DL165 G7 Performance, DL360 G7 Central Management Server, DL360 G7 Efficiency, DL360 G7 Special Server, DL360p Gen8, DL360p Gen8 Base, DL360p Gen8 CMS, DL360p Gen8 Entry, DL360p Gen8 High Performance, DL360p Gen8 Special Server, DL370 G6 High Performance, DL370 G6 Special Server, DL380 G6, DL380 G7 Special Server, DL380p Gen8, DL380p Gen8 Base, DL380p Gen8 Entry, DL380p Gen8 High Performance, DL380p Gen8 Special, DL385 G6 Performance, DL385p Gen8, DL385p Gen8 Dedicated Workload, DL385p Gen8 Entry, DL385p Gen8 Maximized Consolidation, DL385p Gen8 Storage, DL560 Gen8, DL560 Gen8 Base, DL560 Gen8 Entry, DL560 Gen8 Performance, DL580 G5 Highly Serviceable Tower, DL580 G7 Base, DL580 G7 High Performance, DL585 G7 Performance, DL980 G7, MicroServer, MicroServer Gen8, ML10 Entry, ML110 G7, ML110 G7 Base, ML110 G7 Entry, ML110 G7 Performance, ML310e Gen8, ML310e Gen8 Base, ML310e Gen8 Entry, ML310e Gen8 Performance, ML310e Gen8 v2, ML350e Gen8, ML350e Gen8 Base, ML350e Gen8 Entry, ML350e Gen8 Performance, ML350e Gen8 v2, ML350e Gen8 v2 Base, ML350p Gen8, ML350p Gen8 Special Server, ML370 G6 Special Server, SL160s G6, SL165s G7, SL230s Gen8 1U Left Half Width Tray, SL230s Gen8 1U Right Half Width Tray, SL230s Gen8 Base 1U Left Tray Server, SL230s Gen8 Base 1U Right Tray Server, SL250s Gen8 2U Left Half Width Tray, SL250s Gen8 2U PCIe Gen3 Left Tray, SL250s Gen8 2U PCIe Gen3 Right Tray, SL250s Gen8 2U Right Half Width Tray, SL250s Gen8 Base 2U Left Half Width Tray, SL250s Gen8 Base 2U Right Half Width Tray, SL270s Gen8 1U Left Half Width Tray, SL270s Gen8 1U Right Half Width Tray, SL270s Gen8 Base 4U Left Half Width Tray, SL270s Gen8 Base 4U Right Half Width Tray, SL270s Gen8 SE 4U Left Tray, SL270s Gen8 SE 4U Right Tray
HPE StorageWorks Network Storage Gateway X3800 G2
HPE StorageWorks Network Storage System X1400 G2, X1800, X1800 G2 |
|
